the flagship Mondraker e-MTB that boasts a new level of performance, achieved from the latest frame design and ZERO suspension kinematics, with seamless integration of the powerful new Avinox drive system.
Mullet
170mm
165mm
Avinox
800 Wh
Carbon
With 165mm of rear wheel travel, a mixed wheel configuration as standard and the next evolution of the ZERO suspension platform, ZENDIT is by far the most capable Mondraker bike to date.
Components
Frame
Zendit Stealth Air full Carbon, Updated Zero Suspension System, 165mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock
Fox Float X2 Factory Kashima 205x65mm. 2-positions lever compresion (Open/Firm), low-speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings.
Shock settings
CS 30 compression, 1,1 Bleed, RS40 rebound, Rezi B40, LML, Long MCU, 0 volume spacers.
Fork
Fox Podium 29 Float GRIP X2 Factory Kashima, 170mm, tapered steerer tube, Boost 20x110mm thru axle, 44mm offset. High and low-speed compression, high and low-speed rebound, air preload.
Fork remote
N/A
Headset
Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs, with blocklock: S, M / without blocklock: ML, L, XL.
Stem
Onoff S9 30mm 0º, Full CNC, 31.8mm barbore.
Handlebar
Onoff S9 1.0 Carbon, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size.
Seatpost
RockShox Reverb AXS, diameter 31.6mm, w/AXS Pod Controller Rocker Paddle. S size: 398.2x125mm, M size: 448.2x150mm,ML size: 498.2x175mm, L size: 548.2x200mm, XL size:548.2x200mm.
Saddle
Ergon SM10 E-Mountain Black.
Front brake
Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Rear brake
Sram Maven Ultimate, 18 millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads
Brake lever
Sram Maven Ultimate , Carbon lever, SwingLink and lever pivot bearings, tools-free reach adjust
Rims
DT Swiss, Carbon
Spokes
DT Hybrid II Straightpull, w/DT ProLock Squorx ProHead aluminum nipples, Three-cross (1:1) pattern.
Front hub
DT Swiss 350, 20x110mm Boost, Disc IS (6-bolt).
Rear hub
DT Swiss 350, 12x148mm Boost, Disc IS (6-bolt), Sram XD Steel (SRAM) freehub body, 72T Ratchet DEG DF System.
Front tire
Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, DD protection, 120x2TPI, folding bead
Rear tire
Maxxis Minion DHR II 27.5x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 120x2TPI, folding bead
Crankset
e*thirteen Helix Race Carbon e*spec. All sizes: 155mm
Rings
Sram XX Eagle 36T T-Type, 104BCD, steel, CL55
Bottom bracket
N/A
Pedals
N/A
Chain
Sram GX Eagle T-Type, 12s, w/Powerlock
Front derrailleur
N/A
Rear derrailleur
Sram X0 Eagle AXS T-Type, 12s
Shift levers
Sram Eagle AXS Pod Controller Rocker Paddle w/discrete clamp, 12s
Casette
Sram XS 1275, 10-52T, T-Type, 12s
Derailleur hanger
Not included - UDH compatible
Weight
23.1 Kg
Display
Avinox DP100 Display / Avinox BC100 Wireless Controller (L&R)
Motor
Avinox Drive Unit
Battery
Avinox 800Wh Battery / Avinox 12A Charger
