ADVENTURE ON AND OFF-ROAD RIDING
LONG DISTANCE COMMUTING
GRAVEL RIDING
Fully loaded bikepacking, fast and light off-road adventures, gravel and CX racing… or simply exploring your favorite tracks and trails. The Marin Headlands is a high tech, high-spec carbon fiber gravel and adventure bike that’s made to be lightning-fast, confidence-inspiring and super comfortable on all surfaces.
We’ve taken our own unidirectional carbon fiber frame, added mountain bike-inspired geometry, loads of tire clearance and a whole heap of mounting points for gear and fenders to create a super versatile, super capable all-terrain dart of a bike. Go 700c with room for up to 45mm tires or 650b up to 47mm.
The Marin Headlands 1 offers bags of fun, adventure and performance without the loftier price point of the mighty Headlands 2. Gravel-specific Shimano GRX groupset, GRX hydraulic brakes, Vee Tire Co tires and Marin wheels and finishing kit all add up to a whole mountain of fun and adventure.
SPECIFICATIONS
-
FRAME
Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 45mm/650B x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, Internal Dropper Post Routing, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Plentiful Gear Mounts
-
FORK
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
-
RIM
Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible
-
HUB REAR
Forged Aluminum Alloy, Disc, 32H
-
HUB FRONT
Forged Aluminum Alloy, Disc, 32H
-
SPOKES
14g Black Stainless Steel
-
TIRES
Vee Tire Co., G-Sport, 700Cx44, Tubeless Compatible
-
DERAILLEUR REAR
Shimano GRX RDX812 Shadow Plus w/ Clutch
-
DERAILLEUR FRONT
-
-
SHIFT LEVER
Shimano GRX RX600
-
CRANKSET
Forged Alloy 1x11, Hollow CrMo Spindle, Narrow Wide 40T
-
BOTTOM BRACKET
External Sealed Cartridge Bearings
-
CHAIN
KMC X11
-
CASSETTE
Shimano CSM8000, 11-Speed, 11/42T
-
BRAKES FRONT
Shimano GRX Hydraulic Disc, 160mm Rotor
-
BRAKES REAR
Shimano GRX Hydraulic Disc, 160mm Rotor
-
BRAKE LEVERS
Shimano GRX Hydraulic w/ Shifter
-
HANDLEBAR
Marin Butted Alloy, Compact 16º Flared Drop
-
STEM
Marin 3D Forged Alloy
-
GRIPS
Marin Shock Absorbing Tape
-
HEADSET
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
-
SEATPOST
Marin Alloy, 27.2mm
-
SADDLE
Marin Beyond Road Concept
-
PEDALS
-
-
EXTRAS
Bolt-On Thru-Axles F and R
