MONDRAKER F-PODIUM CARBON DC R

£7,299.00
By Mondraker
This product is unavailable

IT’S ALWAYS BEEN OUR OBSESSION TO BUILD BIKES WITH RACING DNA


It’s always been our obsession to build bikes with racing DNA so we designed the F-PODIUM DC R so that you can push yourself to the limit and let the bike get on with the rest. With its STEALTH AIR FULL CARBON frame, ZERO SUSPENSION SYSTEM and FORWARD GEOMETRY you get the most balanced bike possible to compete at the very highest level. Whether you live to find your limits on the climbs or push the envelope on the downs the F-PODIUM DC R just gets on with it. This bike lives to go fast, all the time. Its 115mm of rear travel mated to the RockShox SID Ultimate RL fork offering 120mm at the front provides you with all the assurance you need so that you don't give up a second of hard-won time on the descents that you just fought so hard for on the last climb.
    1. 29

    1. ZERO SUSPENSION SYSTEM

    1. FORWARD GEOMETRY

  1. STEALTH CARBON

COMPONENTS

TECHNICAL SPECS

  • frame

    Frame

    F-Podium 29 Stealth Air Full Carbon, XCO Optimized Zero Suspension System, 115mm, XC Forward Geometry, Carbon Monoblock upper link, BSA bottom bracket, tapered head tube, HHG internal cable routing, dedicated 1X drivetrain design, Boost 12x148mm rear axle, shock mudguard, postmount rear brake mount.


    sizes

    Sizes

    S: 390mm / M: 420mm / L: 470mm / XL: 510mm

  • rear shock

    Rear shock

    Rockshox SID Luxe Ultimate RLR DebonAir, 185x50mm. Settings: OneLoc, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings


    shock settings

    Shock settings

    Light compression, medium rebound, Lockout 430, 1 Token

  • fork

    Fork

    Rockshox SID Ultimate RL 29, 120mm, Charger Race day, DebonAir, tapered steerer tube, Boost 15x110mm axle, 35mm tapered aluminum stanchions, offset 44mm. Settings: OneLoc, Low-speed rebound, air preload


    headset

    Headset

    Acros AZX-239 R1 Block Lock, ZS44/28.6 top, ZS56/40 bottom

  • fork remote

    Fork remote

    RockShox OneLoc


    stem

    Stem

    MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: sizes S/M: 50mm, size L: 60mm, size XL: 70mm

  • handlebar

    Handlebar

    ONOFF Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 760mm, 9º backsweep, 0º upsweep, 31.8mm barbore


    grips

    Grips

    ONOFF Desert, 1lock-on, 135mm

  • seatpost

    Seatpost

    ONOFF Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm


    saddle

    Saddle

    Fizik Antares R7

  • front brake

    Front brake

    Sram Level TL, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad


    rear brake

    Rear brake

    Sram Level TL, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

  • brake lever

    Brake lever

    Sram Level TL, Direct Link actuation, tooled reach adjust, lever pivot bushings


    rims

    Rims

    Mavic CrossMax Carbon XL R, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes

  • spokes

    Spokes

    24 straight-pull double butted spokes


    front hub

    Front hub

    Infinity hub, Boost 15x110mm, IS 6 bolts

  • rear hub

    Rear hub

    Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts


    front tire

    Front tire

    Maxxis Rekon Race 29x2.4, EXO protection, tubeless ready, 120TPI, folding bead

  • rear tire

    Rear tire

    Maxxis Rekon Race 29x2.4, EXO protection, tubeless ready, 120TPI, folding bead


    crankset

    Crankset

    Sram X1 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm, M/L/XL size: 175mm

  • rings

    Rings

    34T, CNC-machined alloy, X-SYNC 2


    bottom bracket

    Bottom bracket

    Sram DUB BSA, sealed bearings, 73mm

  • chain

    Chain

    Sram GX Eagle, 12s, Powerlock


    rear derrailleur

    Rear derrailleur

    Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

  • shift levers

    Shift levers

    Sram Trigger GX Eagle, 12s, X-Actuation 1:1


    casette

    Casette

    Sram XG-1275, 10-50T, 12s

  • derailleur hanger

    Derailleur hanger

    Sram UDH


    weight

    Weight

    11,8 kg
