MONDRAKER CHASER FULL SUSPENSION EBIKE- GRAPHITE/BLACK

£2,999.00 £4,999.00

ENDURO / AM

THEY HELP US TO DISCONNECT FROM OUR DAY TO DAY LIVES AND CONNECT US WITH SPORT AND NATURE

We love our eMTB enduros. They’re exactly what we wanted them to be, they’ve got our Mondraker DNA built in, and they’re what most of us really need from a bike as well. They help us to disconnect from our day to day lives and connect us with sport and nature. In 2023 our eMTB enduros will once again be worldwide benchmarks in their field, and as an added bonus come fitted with the latest upgrades from Bosch or Shimano depending on the model. The CRAFTY family launches the Bosch Smart System motor combined with the all-new minimalist Mini Remote wireless remote control and toptube integrated System Controller. The latter displays the mode you’re in, your remaining battery level and it even lets you change your assistance mode without having to fit the KIOX display if you choose not to. The DUSK family debuts Shimano’s new motors for 2023. Both the EP801 and the EP6 offer spectacular performance. With 85 Nm of torque and 720Wh batteries, we’ll also be offering a 360Wh extender (optional), which gives you up to 1,080Wh for absolutely unheard of range.
  • Frame

    Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard

    Sizes

    S: 380mm / M: 420mm / L: 450mm / XL: 490mm

    Rear shock

    RockShox Deluxe Select R DebonAir, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

    Shock settings

    DebonAir Progressive, Light compression, Linear rebound, 1 Token

    Fork

    RockShox 35 Silver TK 29, 160mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

    Headset

    Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

    Stem

    Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

    Handlebar

    Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

    Grips

    Onoff Twin, 1lock-on, 135mm

    Seatpost

    Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm

    Saddle

    MDK ebike black

    Front brake

    Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

    Rear brake

    Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

    Brake lever

    Sram DB8, tool-free reach adjust

    Rims

    MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

    Spokes

    CN round stainless steel

  • Front hub

    Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

    Rear hub

    Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

    Front tire

    Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

    Rear tire

    Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead

    Crankset

    Race Face Aeffect ebike, 165mm

    Rings

    Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

    Chain

    Sram SX Eagle, 12s, Powerlock

    Rear derrailleur

    Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

    Shift levers

    Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

    Casette

    Sram PG-1210, 11-50T, 12s

    Derailleur hanger

    Mondraker M068

    Weight

    25,2 kg

    Display

    Bosch Kiox 300 / Bosch Led Remote

    Motor

    Bosch Performance Line CX Cruise (25Km/h) Smart System

    Battery

    Bosch Powertube 625Wh
