Marin Gestalt X10 Gravel Bike

$1,849.00

ADVENTURE ON AND OFF-ROAD RIDING

LONG DISTANCE COMMUTING

GRAVEL RIDING

The Gestalt X is our hard-charging, rough-and-rowdy take on what gravel and adventure bikes can do. Break off the fire road, down the singletrack and charge further and faster than ever before. All while keeping the versatility, challenge and fun of a bike with drop handlebars.

The Gestalt X is built with a longer-than-the-usual wheelbase, slack-like-your-mountain-bike head angle, low-slung frame, wide bars, short stem, big and chunky tires with room for up to 50mm on 700c or 54mm with a 650b wheelset.

The Gestalt X10 means extra fun at an extra awesome price. Pick one up and you’ll be riding our MTB-inspired, Series 3 aluminum Gestalt X frame and a whole heap of tough and capable kit, including a 10-speed microSHIFT groupset, cushy and grippy 44mm wide Vee Tire Co tires, Tektro disc brakes and plenty of kick-ass Marin components.

SPECIFICATIONS

  • FRAME

    Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

  • FORK

    Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

  • RIMS

    Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific

  • HUB, REAR

    Forged Aluminum Alloy, Disc, 32H

  • HUB, FRONT

    Forged Aluminum Alloy, Disc, 32H

  • SPOKE, NIPPLES

    14g Black Stainless Steel

  • TIRES

    Vee Tire Co., Rocket Man, 700x44, Tubeless Compatible

  • DERAILLEUR, REAR

    microSHIFT Advent X 10-Speed Wide-Range

  • DERAILLEUR, FRONT

    -

  • SHIFT LEVER

    microSHIFT Advent X 10-Speed

  • CRANKSET

    Forged Alloy 1x10, Hollow CrMo Spindle, Narrow Wide 42T

  • BOTTOM BRACKET

    External Sealed Cartridge Bearings

  • CHAIN

    KMC X10

  • CASSETTE

    SunRace 10-Speed, 11-51T

  • BRAKE, FRONT

    Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor

  • BRAKE, REAR

    Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor

  • BRAKE LEVERS

    microSHIFT Advent X

  • HANDLEBAR

    Marin Butted Alloy, Compact 16º Flared Drop

  • STEM

    Marin 3D Forged Alloy

  • GRIPS

    Marin Shock Absorbing Perforated Tape

  • HEADSET

    FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

  • SEATPOST

    Marin Alloy, 27.2mm

  • SADDLE

    Marin Beyond Road Concept

  • PEDALS

    -

  • EXTRAS

    Bolt-On Thru-Axles F and R

Specifications, pricing, and availability are subject to change without notice.

GEOMETRY

Gestalt X10 geometry diagram
S M L XL
STACK 547.6 566 589.1 621.5
REACH 400 420 440 460
HEADTUBE ANGLE 67.5° 67.5° 67.5° 67.5°
HEADTUBE LENGTH 130 150 175 210
SEATTUBE ANGLE 75° 74° 74° 74°
SEATTUBE LENGTH 460 485 505 530
TOPTUBE EFFECTIVE 546.7 582.3 608.9 638.2
BB HEIGHT 282.5 282.5 282.5 282.5
BB DROP 80 80 80 80
CHAINSTAY 425 425 425 425
WHEELBASE 1065.2 1092.8 1122.4 1155.6
STANDOVER HEIGHT 678.6 687.7 708.6 734.5
FORK OFFSET 50 50 50 50
SEATPOST DIAMETER 27.2 27.2 27.2 27.2
HANDLEBAR WIDTH 440 460 480 480
STEM LENGTH 50 50 50 50
CRANK LENGTH 170 170 175 175

All lengths in millimeters
